Flame-retardant heat shrink tubing that complies with UL 224 (E35586). Delivered with 50.8 mm diameter and can shrink back to 25.4 mm.
Operating temperature from -55°C to +135°C.
Both shrinkage ratios are supplied on reels, 4ft lengths and STDB miniboxes. It is also possible to have the heat-shrink tubing cut to the desired length or to adjust the packaging unit.
LTF100 is a premium quality polyolefin heat shrink tubing designed for use in military and professional electronics applications. Other common uses for this superior grade heat shrink sleeving include insulation of harnesses on military vehicles and communication systems along with use on aircraft, trains and high value, high technology installation
| Material | High Grade Polyolefin |
|---|---|
| Shrink Ratio | 2:1 |
| Standards | UL 224, RoHS, MIL-I-23053/5 class 3 |
| Operating Temperature | -55° tot + 135° C |
| Shrink temp. | > 120° C |
| Dielectric strength | 25kV/mm |
| Chemical resistance | Good |
| Type | Thin Walled Heat Shrink tubing without adhesive |
| SELF EXTINGUISHING? | Yes |
| Halogen Free? | No |
